مستشعر زر ضغط مع شاشة معاينة، لون أسود مطفي GVS KNX

"Weight: 0.05kg

Dimension: 76.8 x 76.8 x 19.3 mm

Bus voltage: 21-30V DC, via the KNX bus

Bus current: <18mA, 24V; <15mA, 30V

Bus consumption: <450mW

Input: 2 external inputs, as dry contact

input or 10K NTC input

Connection: KNX，Bus connection terminal

Input: A three-wires connection terminal,

cable length <5m

Operation: –5 °C ... + 45 °C

Storage: –25 °C ... + 55 °C

Transport: – 25 °C ... + 70 °C

Humidity: <93%,except for dewing

Proximity sensor: Normal sensitivity

approximately 15cm

Enhanced sensitivity approximately 30cm

Mounting: In a conventional 80 or 86 mm

wring box"
