WYW PMR660 Powerd Mixer
The new DEEP2 amp series features four class-H power amplifiers with toroidal core offering amplifying levels from 2 x 400 W till 2 x 810 W at 4 Ohm. During the development of this series we attached a great importance to the reliability and the durability of the amps in continuous operation, this is why we used exclusively high end and selected components for the construction of these products.
Product type
Power Amplifiers
Type
PA Power Amplifiers
Rated ouput power (1kHz @ 2 Ohms)
2 x 800 W
Rated ouput power (1kHz @ 4 Ohms)
2 x 650 W
Rated ouput power (1kHz @ 8 Ohms)
2 x 450 W
Rated ouput power (1 kHz @ 4 Ohms, bridged)
1600 W
Rated ouput power (1kHz @ 8 Ohms, bridged)
1300 W
Output circuitry
Class H
Frequency response
20 - 20000
Total Harmonic Distortion (THD)
< 0.1 %
Signal-to-noise ratio
106 dB
Damping factor (20Hz-500Hz @8ohm)
>400
Crosstalk
>80 dB
Gain
39 dB
Input sensitivity
0.775 V
Protection circuits
clip limiter, DC protection, Short circuit, thermal overload
Controls
2 x volume, bridge/stereo mode selector, ground lift, mains switch (on/off)
Indicators
level, Limit, Power, Protect (protection circuit engaged), Signal
Loudspeaker outputs
2
Speaker output connections
Speakon compatible, Terminal posts
Cooling
highly efficient, automatic
Power supply
transformer
Operating voltage
230 V AC / 50-60 Hz
Weight
15,9 kg
Features
Volex mains socket
