GVS KNX Multifunctional Actuator 4-fold with Secure 6A, 2SU MDRC
Multifunctional Actuator with Secure is a multi-output module, integrating multiple output functions, including switch output, curtain DC/AC output, fan output and valve output. You can configure the functions of the module according to your requirement, such as a part of the output for controlling the switch, a part of the output for controlling the curtain, and a part of the output for controlling the fan.
"Dimension/Weight:
36 × 90 × 64 mm / 0.20kg (4-Fold)
72 × 90 × 64 mm / 0.30kg (8-Fold)
216 × 90 × 64 mm / 0.70kg (16-Fold)
216 ×90×64 mm / 0.85kg (24-Fold)
Bus voltage: 21~30 V DC, via the KNX bus
Connections, KNX: Via bus connection terminals (0.8mmΦ)
Operation: -5℃ ~+ 45℃
Storage: -25℃ ~+ 55℃
Transport: -25℃ ~+ 70℃
Humidity: <93%, except dewing
Design: Modular installation device (MDRC)"
