Motivity Ampilifier
CLASS-E POWER AMPLIFIER
2 X 450 W@4 OHMS
2 X 300 W@8 OHMS
Technical Parameters-Stereo mode: 2x4 450w each channel, 1 KHz <0.05% T.H.D.
2x8 300w each channel, 1 KHz <0.05% T.H.D.
Bridge mode: 1x8 900w each channel, 1 KHz <0.05% T.H.D.
Frequency response: 20 Hz-20 KHz; +0/-0.3 Db 1w/8
Input sensitivity: 0.775v/1.0v/1.4v
Total harmonic distortion: <0.5 Db
Input impedance: ＞ 20K / ＞ 10K
Signal to noise ratio: ＞ 105 dB
Dynamic range: ≥90 dB
Damping coefficient: >200
Slew rate: >15 V/us
Voltage gain: 30 Db
Output type: class E
Protection function: High temperature protection, DC protection, power on protection, overload protection.
External power source: 220v-240v/50-60 Hz
Dimension (WxDxH) : 483x430x88mm
Weight: G.W.16 kg
