LD System Active 12" 2-way bass-reflex PA Loudspeaker
Active Speaker
Active 12" 1" monitor / fullrange loudspeaker with integrated DSP
Integrated Class D power amplifier
Power: 500 watts RMS (1000 watts peak)
Maximum level: 131 dB
Frequency range: 58 - 20,000 Hz
Integrated DSP with the following protected circuit designs: Multiband limiter, overheating, overvoltage, overcurrent
Switchable operating modes: Full-Range, Satellite, Monitor, Flat
BMS tweeter
Dispersion pattern (H x V): 90 x 50°
Connection panel with 2 x Mic / Line combi input, 1 x XLR out, PowerTwist power connection
Multiplex housing
36 mm dual tilt stand flange mount
M10 Rigging points
Dimensions: 390 x 627 x 377 mm
Weight: 20.6 kg
